APM PRINT - CAP88 high speed cap printing machine with auto feeding system Other
CAP88 high speed cap printing machine with auto feeding system companies spend so much time coming up with various products to reach diverse consumer needs. The technology greatly improves product performance and accelerates the manufacturing process.It has a considerably expanded application range and is popular in the field(s) of Pad Printers. Combining all good performance of adopted raw materials, our CAP88 high speed cap printing machine with auto feeding system has been proved to be applied to the field(s) of Pad Printers.Our staff has tested multiple times that in the applied fields, the product can give out its best performance such as durability and stability.
| Type: | PAD PRINTER | Applicable Industries: | Manufacturing Plant |
| Condition: | New | Plate Type: | PAD PRINTER |
| Place of Origin: | Guangdong, China | Brand Name: | APM |
| Usage: | cap printer | Automatic Grade: | Automatic |
| Color & Page: | Multicolor | Voltage: | 110V/220V |
| Dimensions(L*W*H): | 3.5*1.3*2m | Weight: | 800KGS |
| Warranty: | 1 Year | After-sales Service Provided: | Free spare parts, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas |
| Certification: | CE Certification | Product name: | Automatic Pad Printing Machine |
| Application: | water caps | Printing color: | 1~4 color |
CAP88H high speed cap printing machine
Caps Master is a fully automatic pad printing system for caps printing. It is combined with auto loading, caps locking, flame treatment, printing, drying and unloading all in 1 system. Easy setting up, fast and durable running makes Caps Master a stable and economic solution for caps printing.
Application:
Beverages caps, wine caps, medicine caps, oil caps
Description:
Automatic loading with hopper and mechanical loading system
Auto flame treatment with electric ignition and air exhausting system
1~5 colors printing
Automatic heating system after printing to dry the caps
Motor driven conveyor, conveyor chain made in Japan
Auto unloading
Auto pad cleaning optional
Well built machine closure
CE standard safety design
PLC control, touch screen display
Tech-data:
Tech-data: | CAP88H |
Ink tray size | 190*180mm |
Max. printing size | 160*160mm |
Pad front/back stroke | 275 |
Up/down stroke | 150mm |
Plate size | 186*178*10mm |
Printing speed | Standard speed: 15000pcs/h for 28mm caps, max. speed: 20000psc/h |
Gross weight | 600 kgs |
Measurement(l*w*h) | 400x120x221cm |
Color registration tolerance: | +/-0.1mm |
Power supply | 240V single phase 50/60Hz |
Air supply | 8bar, at least 6bar. |
Spare parts and consumables:
Fixture
Sorter
Plate
Pad
Blade
Ink
Tape for pad cleaning
